UPE PROFILE WITH DIMENSIONS FROM 80 TO 400 MM
Technical characteristics:
Manufacturing tolerances according to: EN 10279. The standard regulates the conditions relating to tolerances on dimensions, shape, and mass of hot-rolled U profiles (channels) made of steel.
Steel quality: S 235, S 275, S 355 according to EN 10025 – 2
Manufacturing lengths: 6 and 12 m
Standard Manufacturing / Delivery Dimensions
| Designation | Weight | Dimensions (mm) | Section | Section Modulus | |||||
| kg / ml | cm² | mm³ | |||||||
| h | b | s | t | r | Avz | Wz | Wely | ||
| UPE 80 | 7.9 | 80 | 50 | 4.0 | 7.0 | 10 | 4.05 | 8.00 | 27 |
| UPE 100 | 9.82 | 100 | 55 | 4.5 | 7.5 | 10 | 5.34 | 10.60 | 41 |
| UPE 120 | 12.1 | 120 | 60 | 5.0 | 8.0 | 12 | 7.18 | 13.80 | 61 |
| UPE 140 | 14.5 | 140 | 65 | 5.0 | 9.0 | 12 | 8.25 | 18.20 | 86 |
| UPE 160 | 17.0 | 160 | 70 | 5.5 | 9.5 | 12 | 10.00 | 22.60 | 114 |
| UPE 180 | 19.7 | 180 | 75 | 5.5 | 10.5 | 12 | 11.20 | 28.60 | 150 |
| UPE 200 | 22.8 | 200 | 80 | 6.0 | 11.0 | 13 | 13.50 | 34.50 | 191 |
| UPE 220 | 26.6 | 220 | 85 | 6.5 | 12.0 | 13 | 15.80 | 42.50 | 224 |
| UPE 240 | 30.2 | 240 | 90 | 7.0 | 12.5 | 15 | 18.80 | 50.10 | 300 |
| UPE 270 | 35.2 | 270 | 95 | 7.5 | 13.5 | 15 | 22.20 | 60.70 | 389 |
| UPE 300 | 44.4 | 300 | 100 | 9.5 | 15.0 | 15 | 30.30 | 75.60 | 522 |
| UPE 330 | 53.2 | 330 | 105 | 11.0 | 16.0 | 18 | 38.80 | 89.70 | 667 |
| UPE 360 | 61.2 | 360 | 110 | 12.0 | 17.0 | 18 | 45.60 | 105.00 | 824 |
| UPE 400 | 72.2 | 400 | 115 | 13.5 | 18.0 | 18 | 56.20 | 123.00 | 1050 |
